NUP 207 ECM Single Row Cylindrical Roller Bearing 35x72x17 Mm
NUP 207 ECM Single Row Cylindrical Roller Bearing 35x72x17 mm
Cylindrical Roller Bearing, NUP 207 ECM, 35x72x17 mm, Brass Cage, Single Row, No Seal, No Separable; No Snap Ring, Relubricatable, C0.
Single row cylindrical roller bearings are designed to accommodate high radial loads in combination with high speeds. Having two integral flanges on the outer ring and one integral flange and one loose flange ring on the inner ring, NUP design bearings can locate the shaft axially in both directions. An important feature is the separable design, which facilitates mounting and enables the bearing components to be interchanged.
EC: Optimized Internal Design Incorporating More And/Or Larger Rollers And With Modified Roller/End Flange Contact.
M: Solid Brass Cage, Two Piece, Roller Guided
|
Part Number |
NUP207ECM |
Package |
Carton Box+Pallet |
|
Size: |
35x72x17 mm |
Material |
Bearing steel |
|
Bore diameter (d): |
35 mm (1.378 Inch) |
Place of Origin |
Germany |
|
Outside Diameter (D): |
72 mm (2.835 Inch) |
Structure |
Cylindrical Roller Bearing |
|
Width, outer ring (T): |
17 mm (0.669 Inch) |
Sealing |
No seal |
|
Profile |
Complete with Outer and Inner Ring |
Grease Limiting Speed (r/min) |
11000 r/min |
|
Relubricatable |
Yes |
Oil Limiting Speed (r/min) |
12000 r/min |
|
Radial internal clearance |
C0 |
Cage |
Brass Cage |
|
Precision Grade |
P6, P5, P4 |
Certifications |
ISO9001:2015 |
|
Number of Row |
1 |
Basic dynamic load rating |
56 kN |
|
MOQ |
1PCS |
Basic static load rating |
48 kN |
|
Weight |
0.365 KG |
Lead Time |
3~5 Days |
|
Payment Term |
TT or Western Union |
Application |
Manufacturing Plant, Energy & Mining |
|
Brand Name |
As per requirement |
Snap Ring |
No |
|
Bore Type |
Cylindrical |
Seperable |
No |
|
Bore Profile |
Straight |
Heat Stabilization |
Temperatures up to 120 °C |
|
Retainer |
Yes |
Other Features |
1 Rib Inner Ring with Side Plate, 2 Rib Outer Ring, Cage on Outer Ring ID |
|
Design |
NUP |
Number of flanges, outer ring |
2 |
|
Number of flanges, inner ring |
1 |
Loose flange |
Inner ring loose flange |
|
Tolerance Class |
Normal |
D1 |
60.33 mm |
|
d1 |
48.1 mm |
r1,2 min. |
1.1 mm |
|
F |
44 mm |
r3,4 min. |
0.6 mm |
|
da min. |
41.8 mm |
Da max. |
65.1 mm |
|
db min. |
50 mm |
Fatigue load limit (Pu) |
6.1 kN |
|
ra max |
1 mm |
kr |
0.15 mm |
|
e |
0.2 mm |
Y |
0.6 mm |
