NU 305 ECP Single Row Cylindrical Roller Bearing 25x62x17 Mm

Get Latest Price

Min. Order:

1 Piece

Stock:

780 Piece

Production Capacity:

100000pcs/year

Port:

Shanghai/Qingdao/Guangzhou/Hongkong

Payment term:

TT/Western Union/Paypal

Delivery time:

3~5 days

Technical Parameters:

Product Designations:

NU 305 ECP

Old Designations:

NU305ECP

HS Code:

8482500090

Structure:

Cylindrical Roller Bearing

Number of Rows:

Inside Diameter:

25 mm

Outside Diameter:

62 mm

Thickness:

17 mm

Weight:

0.234 KG

Dynamic load Capacity, Radial (Cr):

46.5 kN

Static load Capacity, Radial (Cor):

36.5 kN

Reference speed (Grease rpm):

12000 1/min

Limiting speed (Oil rpm):

15000 1/min

Demensions:

25x62x17 mm

Brand:

As Per Requirements

Radial Clearance Trade No.:

Precision Rating:

P6 P5 P4

Vibration:

ZV1/ZV2/ZV3

Load Direction:

Axial/Radial

Bearing Material:

Bearing Steel

Cage Type:

Steel Cage

Cage material:

Steel

Seals Type:

Open

Roller Material:

Bearing Steel

Fatigue Load Limit, Radial:

4.55 kN

Transport Package:

Box+Pallet

Shipping Ways:

DHL / TNT / UPS / ARMEX / FEDEX ,Etc

Country of Origin:

Germany

Service:

OEM Service

Quality Control:

ISO9001:2015

Feature:

2 Rib Outer Ring, Cage on Outer Ring ID, Light Capacity, X Life Bearing

Bore Type:

Cylindrical

Operating Temperature Range:

Up to 120 °C

Series:

Rolling Element:

Cylindrical roller bearing

Suffix Description:

EC: Optimized Internal Design Incorporating More And/Or Larger Rollers And With Modified Roller/End Flange Contact. P: Injection Moulded Cage Of Glass Fibre Reinforced Polyamide 6,6, Roller Centered

Snap Ring:

Application:

gearboxes, agricultural machinery, pumps, compressors, and electric motors.

NU 305 ECP Single Row Cylindrical Roller Bearing 25x62x17 mm

Cylindrical Roller Bearing, NU 305 ECP, 25x62x17 mm, Steel Cage, Single Row, No Seal, Inner Ring-Two Side Separable; No Snap Ring, Relubricatable, C0.

The NU 305 ECP is a single-row cylindrical bearing with NU design. The outer ring of this bearing has two rigid ribs, while the inner ring has none. As a result, NU bearings are only capable of supporting radial forces. This bearing type is commonly used as a floating bearing. Floating bearings allow axial displacement of the shaft relative to the housing in both directions. This is necessary in applications where the shaft material shrinks or expands due to temperature changes (thermal expansion). NU bearings can also be used as support bearings by combining them with HJ angle rings (available separately). Support bearings can support radial forces and also axial forces in a single direction.

EC: Optimized Internal Design Incorporating More And/Or Larger Rollers And With Modified Roller/End Flange Contact.

P: Injection Moulded Cage Of Glass Fibre Reinforced Polyamide 6,6, Roller Centered

Part Number	NU 305 ECP	Package	Carton Box+Pallet
Size:	25x62x17 mm	Material	Bearing steel
Bore diameter (d):	25 mm (0.984 Inch)	Place of Origin	Germany
Outside Diameter (D):	62 mm (2.441 Inch)	Structure	Cylindrical Roller Bearing
Width, outer ring (T):	17 mm (0.669 Inch)	Sealing	No seal
Profile	Complete with Outer and Inner Ring	nG	12000 1/min
Relubricatable	Yes	nB	15000 1/min
Radial internal clearance	C0	Cage	Steel Cage
Precision Grade	P6 P5 P4	Certifications	ISO9001:2015
Number of Row	1	Basic dynamic load rating	46.5 kN
MOQ	1PCS	Basic static load rating	36.5 kN
Weight	0.234 KG	Lead Time	3~5 Days
Payment Term	TT or Western Union	Application	gearboxes, agricultural machinery, pumps, compressors, and electric motors.
Brand Name	As per requirement	Snap Ring	No
Bore Type	Cylindrical	Seperable	Inner Ring-Two Sides
Bore Profile	Straight	Heat Stabilization	Temperatures up to 150 °C
Retainer	Yes	Other Features	2 Rib Outer Ring, Cage on Outer Ring ID, Light Capacity, X Life Bearing
Design	NU	Fatigue load limit (Pu)	4.55 kN
D1	50.25 mm	F	34 mm
r1,2 min	1.1 mm	r3,4 min	1.1 mm
da min	77 mm	db min	85 mm
s max	1.3 mm	da min	31 mm
da max	32.5 mm	db min	36 mm
Da max	54.9 mm	ra max	1 mm
rb max	1 mm	kr	0.15 mm
e	0.2 mm	Y	0.6 mm

Please contact Cherry if you are interested in this product:

WhatsApp: +86 13825082601

Mobile: +86 18928876761

Share this product to:

Let more people see your product

How can you buy NU 305 ECP Single Row Cylindrical Roller Bearing 25x62x17 Mm on the Internet?
High quality NU 305 ECP ( 0.234 kg Mass, ID: 25 mm OD: 62 mm WD: 17 mm , NU Series , 1 Rows , C0 Radial Clearance , P6 P5 P4 Accuracy Class , Bearing Steel Material , 46.5 kN Radial dynamic , 36.5 kN Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. NU 305 ECP. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
