HH224335/HH224310CD Tapered Roller Bearing (Size:4x8.375x5.6249 Inch)

Get Latest Price

Min. Order:

1 Piece

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Mobile NO.: +86-18062246726

Technical Parameters:

Product Designations:

HH224335/HH224310CD

HS Code:

8482500090

Structure:

Roller Bearing

Number of Rows:

Double

Inside Diameter:

101.6 mm

Outside Diameter:

212.725 mm

Thickness:

142.872 mm

Weight:

22.87 KG

Demensions:

101.6x212.725x142.872

Brand:

Neutral Product

Precision Rating:

Standard

Load Direction:

Radial and Thrust

Bearing Material:

Chrome Steel (Gcr15)

Cage material:

Steel

Roller Material:

Chrome Steel (Gcr15)

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Operating Temperature Range:

-40℃ to 120℃

System of Measurement:

Inch

Series:

HH224300

Rolling Element:

Roller

Cone Number:

HH224335

Cup Number:

HH224310CD

Cone Width (B):

66.675

Cup Width (C):

117.475

Chamfer (R):

7.1

Chamfer (r):

1.5

Application:

Gearboxes, Hoisting Equipment, Rolling Mills and Machines in the Mining Industry, e.g. tunnelling machines.

HH224335/HH224310CD Tapered Roller Bearing, TDO Type, Double Row, Inch Size.

Size (Inner Dia x Outer Dia x Bearing Width Across Cones): 4x8.375x5.6249 Inch (101.6x212.725x142.872 mm)

Cone Part No.: HH224335

Cup Part No.: HH224310CD

Mini Operating Temperature:-40 °C

Max Operating Temperature:120 °C

HH224335/HH224310CD Tapered Roller Bearing consists of two single inner rings (Cone) HH224335 and a single piece (double) outer ring (Cup) HH224310CD. Besides, it is usually supplied complete with an inner-ring spacer as a pre-set assembly.

HH224335/HH224310CD Tapered Roller Bearing
Type:	TDO
Series:	HH224300
Cone Part Number:	HH224335
Cup Part Number:	HH224310CD
Bearing Weight (kg)	22.87
Main Dimensions:
	inch	mm
d-Bore:	4	101.6
D-Cup Outer Diameter:	8.375	212.725
B-Cone Width:	2.625	66.675
C-Double Cup Width:	4.625	117.475
T-Bearing Width Across Cones	5.6249	142.872
Bearing Type:	Roller
Ring Material:	Chrome Steel
Roller Material:	Chrome Steel
Cage Material:	Stamped Steel
Precision:	Standard Precision
Load Direction:	Combined Radial and Thrust
Country of Origin:	China
HS Code:	8482500090

The configuration of the TDO provides a wide effective bearing spread, making it ideal for applications in which overturning moments are a significant load component. TDO bearings can be used in fixed positions or allowed to float in the housing bore.

Applications: gearboxes, hoisting equipment, rolling mills and machines in the mining industry, e.g. tunnelling machines.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at sales@partsservicesupply.com or contact us by Wechat or Whatsapp at +8618062246726.
