luoyang mc bearing technology co., ltd
Free Member
External toothed EB2.28.1215.200-1SPPN double row ball bearing slewing ring

External Toothed EB2.28.1215.200-1SPPN Double Row Ball Bearing Slewing Ring

Reference FOB Price:
US100 ~ 1500 / Piece
Min. Order:
1 Piece
Stock:
100 Piece
Production Capacity:
100pc/month
Port:
shanghai, qingdao, tianjin, ningbo, guangzhou
Payment term:
fob, cif, exw
Delivery time:
15-45days
Technical Parameters:
Product Designations:
EB2.28.1215.200-1SPPN
HS Code:
8482109000
Structure:
double row slewing ball bearing
Number of Rows:
double row
Inside Diameter:
1095 mm
Outside Diameter:
1380 mm
Thickness:
108 mm
Weight:
325 KG
Limiting speed (Oil rpm):
EP2
Demensions:
1380*1095*108
Brand:
LYMC
Precision Rating:
P0, P6, P5, P4, P2
Bearing Material:
42CrMo/50Mn/45#/custom
Cage material:
Nylon/steel/copper
Seals Type:
open
Seal Material:
NBR
Ball Material:
GCr15
Roller Material:
GCr15
Transport Package:
export wooden cases
Shipping Ways:
sea, air, express, train
Country of Origin:
China
Service:
reply within 24 hours, oem service, design service, technical support
Quality Control:
iso9001, QC report
Outer Ring Width:
98
Inner Ring Width:
98
Rolling Element:
steel ball
Gear Options:
external gear
Application:
Cranes, Aerial lifts, Excavators, Wind turbines, Utility derricks, Log loaders and feller bunchers, Grapples, Mining equipment
External Toothed EB2.28.1215.200-1SPPN Double Row Ball Bearing Slewing Ring

External toothed EB2.28.1215.200-1SPPN double row ball bearing slewing ring

material:42crmo/50mn/45#/custom

structure:double row slewing ball bearing

gear option:external gear, internal gear, non gear

raceway hardness:55-62HRC

outer ring dia(De):1380mm

inner ring dia(Di):1095mm

thickness/width(H):108mm

Mounting hole dia(Fe):1290mm

Mounting hole dia(Fi):1135mm

outer ring width/thickness(He):98mm

inner ring width/thickness(Hi):98mm

Mass:325kgs

More types for you:

EB2.22.0307.200-1SPPN
EB2.22.0383.200-1RPPN
EB2.25.0475.200-1RPPN
EB2.25.0575.401-1RPPN
EB2.20.0752.200-1RPPN
EB2.25.0821.400-1RPPN
EB2.20.0968.200-1SPPN
EB2.25.1077.400-2RPPN
EB2.28.1215.200-1SPPN

Luoyang MC Bearing Technology Co.,Ltd (LYMC),who is manufacture located in bearing zone, focus on Slewing bearing, cross roller bearing and pinion,Dia from 50mm-8000mm, Our team with technical and full experience in the bearing industry.

Double row ball slewing bearings
This kind of bearings can support high static loads with simple structures. They are mainly used in situations with variation load position and direction and continuously rotating. Main applications of this kind of bearings are deck hoisting, mining and material handling etc.

Packaging:

1.Filling with anti-rust oil
2.Corved with Plastic paper
3.Corved with kraft paper
4.Corved with Blue tie
5.Put in wooden box

Delivery time:

within 7 working days with stock(standard slewing bearing)

within 35-45 working days without stock(non-standard slewing bearing)

Payment term:T/T

If any interesteed items or inquiry, please feel free to contact us. All inquiry will be replied within 24 hours.


Share this product to:     Let more people see your product
How can you buy External Toothed EB2.28.1215.200-1SPPN Double Row Ball Bearing Slewing Ring on the Internet?
High quality EB2.28.1215.200-1SPPN ( 325 kg Mass, ID: 1095 mm OD: 1380 mm WD: 108 mm , double row Rows , P0, P6, P5, P4, P2 Accuracy Class , 42CrMo/50Mn/45#/custom Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. EB2.28.1215.200-1SPPN. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
