CSF-40-160-2A-GR Harmonic Drive / Speed Reducer / Strain Wave Gearing
Min. Order:
1 Piece
Payment term:
T/T ; Western Union; Moneygram ; Paypal
Delivery time:
3 ~ 5 working days
Mobile NO.: +86 15606176717
Technical Parameters:
Product Designations:
CSF-40-160-2A-GR
Structure:
Harmonic Drive
Inside Diameter:
10 ~ 1000 mm
Outside Diameter:
10 ~ 1000 mm
Thickness:
10 ~ 1000 mm
Weight:
1.70 KG
Brand:
As Per Requirements
Precision Rating:
High Precision
Bearing Material:
Steel Casting
Seals Type:
Optional
CSF-40-160-2A-GR Harmonic Drive / Speed Reducer / Strain Wave Gearing
Stock QTY : 60.pcs (More on the way)
| Model Number | CSF-40-160-2A-GR |
| Series | CSF |
| Size | 40 |
| Reduction Ratio | 1/160 |
| Type | 2A-GR |
| Weight | 1.70 KG |
| Country Origin | JAPAN |
| MOQ | 1.PCS |
| Shipping Way | DHL / TNT / UPS / FEDEX ,Etc. |
|
hannabearing@hotmail.com |
| Gear Performance Data | ||
|---|---|---|
| Rated Torque L10 | 294 | Nm |
| Limit for Average Torque | 451 | Nm |
| Limit for Repeated Peak Torque | 647 | Nm |
| Limit for Momentary Peak Torque | 1,180 | Nm |
| Starting Torque | 21 | Ncm |
| Backdriving Torque | 40 | Nm |
| Ave. Input Speed | 3,000 | rpm |
| Standard Accuracy | 1 | arc min |
| Mass | 1.7 | kg |
| Torsional Stiffness | ||
|---|---|---|
| T1 | 54 | Nm |
| K1 | 13 | 10^4 Nm / rad |
| T2 | 196 | Nm |
| K2 | 20 | 10^4 Nm / rad |
| K3 | 23 | 10^4 Nm / rad |
If you are interested in CSF-40-160-2A-GR Harmonicdrive,feel free to contact us by click the " Contact Now " button or by informaton given as below:
| Skype | hannagreenpower |
| 0086-137 7145 6936 | |
| 0086-137 7145 6936 | |
| hannabearing@hotmail.com |
Besides,if you need any other Harmonic Drive,please feel free to send us the Inquiry!
