7602030-TVP Axial Angular Contact Ball Bearings

Get Latest Price

Min. Order:

1 Piece

Payment term:

T/T

Delivery time:

Within 3 Working Days

Mobile NO.: +86 15606176717

Technical Parameters:

Product Designations:

7602030-TVP

Structure:

Angular contact

Inside Diameter:

30 mm

Outside Diameter:

62 mm

Thickness:

16 mm

Weight:

0.232 KG

Precision Rating:

P0~P2

Bearing Material:

Bearing Steel

Seals Type:

Optional

7602030-TVP Axial angular contact ball bearings 30x62x16mm

d	30 mm
D	62 mm
B	16 mm
a	48 mm
Da H12	52,5 mm
da h12	39,5 mm
ra max	1 mm
rmin	1 mm
m	0,232 kg	Mass
Ca	27500 N	Basic dynamic load rating, axial
C0a	66000 N	Basic static load rating, axial
Fa max	17000 N	Maximum axial force, dynamic
nG Fett	3800 1/min	Limiting speed for grease lubrication
nG Öl	5000 1/min	Limiting speed for minimal quantity oil lubrication
Fv	2900 N	Preload force
Mr	85 Nmm	Frictional torque
Cua	5900 N	Fatigue limit load, axial

PE : Less stringent bearing design
T, TVP : Polyamide cage, guided by balls
2RS : Contact seals on both sides
2Z : Gap seals on both sides
2AP : Axial angular contact ball bearings, matched pair (ZKLN, ZKLF)

In series 7602, 7603 and BSB, the polyamide cages are indicated by the suffix TVP or T.Screw drive bearing arrangements are subjected to requirements that often cannot be optimally fulfilled by the design construction of conventional bearings.

Due to the contact angle of 60°, the bearings can support not only radial forces but high axial forces as well.Bearings 7602, 7603 and BSB are designed as universal bearings.

We have 889.00 sets in stock . If you have reuqirements for the bearings given as above, please feel free to contact us.We can assure you the best quality ;the most competitive prices ; the shortest delivery time and the highest quality service.
