Hubei Parts Service Supply Co., Ltd.
758/752-B Single Row Tapered Roller Bearing Size 3.375x6.375x1.9 Inch

758/752-B Single Row Tapered Roller Bearing Size 3.375x6.375x1.9 Inch

Min. Order:
1 Piece
Stock:
100 Piece
Port:
Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao
Payment term:
by T/T in advance
Delivery time:
2-3 days for stock, 25-30 days for bulk production
Skype online
QQ online
Mobile NO.: +86-18062246726
Technical Parameters:
Product Designations:
758/752-B
HS Code:
8482500090
Structure:
Roller Bearing
Number of Rows:
Single
Inside Diameter:
85.725 mm
Outside Diameter:
161.925 mm
Thickness:
48.26 mm
Weight:
4.38 KG
Demensions:
85.725x161.925x48.26
Brand:
Neutral Product
Radial Clearance Trade No.:
Standard
Precision Rating:
Standard
Load Direction:
Radial and Thrust
Bearing Material:
Chrome Steel (Gcr15)
Cage material:
Steel
Roller Material:
Chrome Steel (Gcr15)
Transport Package:
Standard Export Package
Shipping Ways:
by Sea or Air
Country of Origin:
China
Operating Temperature Range:
-40℃ to 120℃
System of Measurement:
Inch
Series:
755
Rolling Element:
Roller
Cone Number:
758
Cup Number:
752-B
Cone Width (B):
48.26
Cup Width (C):
38.1
Chamfer (R):
3.6
Chamfer (r):
3.3
Application:
Construction, Transportation and Agricultural Machinery, Conveyor Plants, Hydraulic Jacks, and other industry.
758/752-B Single Row Tapered Roller Bearing Size 3.375x6.375x1.9 Inch

758/752-B Tapered Roller Bearing, Single Row, With Flange.

Cone Part No.: 758

Cup Part No.: 752-B

Size (Inner Dia x Outer Dia x Assembly Width): 3.375x6.375x1.9 inch (85.725x161.925x48.26mm)

Mini Operating Temperature:-40 °C

Max Operating Temperature:120 °C

758/752-B tapered roller bearing (TSF type) consists of two main separable parts: the cone (inner ring) 758 assembly and the cup (outer ring) 752-B. It is typically mounted in opposing pairs on a shaft. TSF bearings have flanged cups to facilitate axial location and accurately align seals in through-bored housings.

758/752-B Tapered Roller Bearing

Type:

TSF (Tapered Single)

Series:

755

Cone Part Number:

758

Cup Part Number:

752-B

Bearing Weight (kg)

4.38

Main Dimensions:



inch

mm

d-Bore:

3.375

85.725

D-Cup Outer Diameter:

6.375

161.925

D1-Flange Outer Diameter:

6.683

169.748

B-Cone Width:

1.9

48.26

C-Cup Width:

1.5

38.1

C1-Cup Flange Width:

0.3120

7.925

T1 - Bearing Width to Flange:

0.687

17.45

Bearing Type:

Roller

Bearing Material:

Chrome Steel

Cage Material:

Stamped Steel

Precision:

Standard Precision

Load Direction:

Combined Radial and Thrust

Country of Origin:

China

HS Code:

8482500090

Applicatioins: Gearing Systems and Transmissions, Thermal Power Coal Transporters, Port Equipment, Rubber and other Industrial applications, Machine Tool Spindles, Gear Reducer, Automotive Drive Axle, Aircraft wheels, Agricultural Wheels, Tensioning Roller, Raking Machine, Construction and Mining Equipment, Railroad Axle-box, etc.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at sales@partsservicesupply.com or contact us by Wechat or Whatsapp at +8618062246726.


Share this product to:     Let more people see your product
How can you buy 758/752-B Single Row Tapered Roller Bearing Size 3.375x6.375x1.9 Inch on the Internet?
High quality 758/752-B ( 4.38 kg Mass, ID: 85.725 mm OD: 161.925 mm WD: 48.26 mm , 755 Series , Single Rows , Standard Radial Clearance , Standard Accuracy Class , Chrome Steel (Gcr15) Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 758/752-B. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
