61920M Bearing 100x140x20mm
Min. Order:
1 Piece
Payment term:
T/T, L/C
Delivery time:
10 days if in stock, normal delivery time if no st
Technical Parameters:
Product Designations:
61920M
Structure:
deep groove ball bearing
Inside Diameter:
100 mm
Outside Diameter:
140 mm
Thickness:
20 mm
Weight:
0.92 KG
Brand:
ESG
Precision Rating:
P6
Bearing Material:
chorome steel
Seals Type:
open
Bearing No.: 61920M
Bearing type: deep groove ball bearing
Application: used in rolling mills for the rolled products.
| Boundary dimensions(mm) | Basic load ratings(kN) | Speed rating | Designations | Weight | |||||
| (rpm) | (kg) | ||||||||
| d | D | B | rmin | Cr | Cor | Grease | Oil | ||
| 100 | 140 | 20 | 1.1 | 30.9 | 37.8 | 3700 | 4900 | 61920M | 0.92 |
More sizes for your choice:
Boundary dimensions(mm) Speed rating Designations
(rpm)
d D B rmin Cr Cor Grease Oil
90 140 24 1.5 40.3 42.5 3900 5200 6018M
95 145 24 1.5 42.3 46.5 3700 4900 6019M
100 140 20 1.1 30.9 37.8 3700 4900 61920M
100 150 24 1.5 44.2 50.6 3500 4700 6020M
110 150 20 1.1 31.6 40.3 3400 4500 61922M
110 170 28 2 55 62.5 3100 4100 6022M
120 165 22 1.1 39.2 50.9 3000 4000 61924M
120 180 28 2 57.1 68.2 2900 3800 6024M
130 180 24 1.5 48.2 63.5 2800 3700 61926M
130 200 33 2 74.3 87.2 2600 3400 6026M
140 190 24 1.5 51 71 2600 3400 61928M
140 210 33 2 80.9 102 2400 3200 6028M
150 210 28 2 62.7 85.2 2300 3100 61930M
150 225 35 2.1 85 110 2200 2900 6030M
150 230 35 2.1 85 110 2200 2900 6030X1M
155 215 28 2 62.4 85.3 2300 3000 61931M
160 220 28 2 64.5 90.5 2200 2900 61932M
160 240 38 2.1 85.8 118 2000 2700 6032M
170 230 28 2 68 100 2000 2700 61934M
170 260 42 2.1 97 137 1900 2500 6034M
170 265 42 2.1 97 37 1900 2500 6034X2-1M
170 270 42 2.1 97 137 1800 2400 6034X2-2M
180 250 33 2 84.6 119 1900 2500 61936M
180 259.5 33 2 90 130 1800 2400 63196X2M
180 259.5 52 2 98 137 1800 2400 63936X1M
180 260 42 2 98 137 1800 2400 62936X2M
180 280 46 2.1 134 180 1700 2300 6036M
190 240 24 1.5 54.6 84.2 1900 2500 61838M
190 260 33 2 90 133 1800 2400 61938M
190 269.5 33 2 90 133 1700 2300 61938X1M
190 290 46 2.1 144 200 1600 2200 6038M
200 250 24 1.5 55.5 87.6 1800 2400 61840M
200 279.5 38 2.1 110 180 1600 2200 61940X1-1M
200 280 38 2.1 110 158 1600 2200 61940M
200 289.5 38 2.1 110 158 1600 2200 61940X1-2M
200 310 51 2.1 159 225 1500 2000 6040M
220 270 24 1.5 57.3 94.2 1600 2200 61844M
220 300 38 2.1 105 162 1500 2000 61944M
220 300 60 2.1 105 162 1500 2000 63944M
220 309.5 38 3 116 178 1450 1930 61944X1M
220 340 56 3 172 265 1350 1800 6044M
230 329.5 40 3 1389 215 1350 1800 61946X3M
240 300 28 2 73.6 122 1400 1860 61848M
240 320 38 2.1 119 186 1350 1800 61948M
240 359.5 56 3 177 286 1230 1640 6048X1M
240 360 56 3 177 286 1230 1640 6048M
250 359.5 46 2.1 157 254 1200 1600 61950X1M
260 320 28 2 76 131 1300 1720 61852M
260 360 46 2.1 163 269 1180 1570 61952M
260 369.5 46 2.1 163 269 1150 1530 61952X1-2M
260 369.5 60 2.1 163 269 1150 1530 62952X1-1M
260 370 46 2.1 163 269 1150 1530 61952X1-1M
260 374.5 60 2.1 163 269 1140 1520 62952X1-2M
260 400 65 4 224 376 1080 1440 6052M
280 350 33 2 99.8 170 1150 1530 61856M
280 375 65 2.1 167 285 1100 1460 62956X3-1M
280 380 46 2.1 168 285 1080 1440 61956M
280 389.5 46 2.1 167 285 1060 1420 61956X1-2M
280 389.5 65 3 181 310 1060 1420 62956X3-2M
280 390 46 2.1 167 285 1060 1420 61956X1-1M
280 420 65 4 232 407 1000 1340 6056M
300 380 38 2.1 114 198 1040 1390 61860M
300 419.5 56 3 198 349 960 1290 61960X1M
300 420 56 3 198 349 960 1290 61960M
300 459.5 74 1 257 473 900 1220 6060X1M
300 460 74 4 257 473 900 1220 6060M
320 400 38 2.1 115 205 960 1290 61864M
320 440 56 3 212 394 900 1220 61964M
320 459.5 70 4 237 442 880 1170 62964X3M
320 480 74 4 269 509 850 1130 6064M
340 420 38 2.1 119 219 900 1220 61868M
340 460 56 3 118 418 850 1130 61968M
340 520 82 5 310 596 800 1050 6068M
360 440 38 2.1 120 226 850 1130 61872M
360 480 56 3 223 438 820 1080 61972M
360 540 82 5 324 649 760 1000 6072M
380 480 46 2.1 178 337 800 1050 61876M
380 520 65 4 250 505 760 1000 61976M
380 560 82 5 336 699 720 950 6076M
400 500 46 2.1 181 350 760 1000 61880M
400 540 65 4 256 533 720 950 61980M
400 600 90 5 361 751 670 880 6080M
420 520 46 2.1 183 363 720 950 61884M
420 560 65 4 262 558 690 900 61984M
420 620 90 5 376 814 630 830 6084M
