609 Bearing

Get Latest Price

Min. Order:

1 Piece

Payment term:

Delivery time:

7 days

Technical Parameters:

Product Designations:

609

Structure:

deep groove ball bearing

Inside Diameter:

9 mm

Outside Diameter:

24 mm

Thickness:

7 mm

Weight:

0.015 KG

Precision Rating:

ABEC-5

Bearing Material:

Chrome Steel

Seals Type:

Open,ZZ,2RS,Z,RS

Item: Deep Groove Ball Bearings

1)ISO 9001:2008 approved.
2)long life and low noise
3)OEM service
4)stocks

Specifications

Material :GCr15/GCr15SiMn / G20Gr2Ni4A
Hardness :HRC60-HRC64
Closures :Unsealed/Sealed Grade : P5

Clearance :C0, C3, C4

Lubrication :Oil or grease
Features: These bearings are featured by the extremely big axial load carrying capacity and meanwhile they can also carry certain radial load

Packing :
1. For small ones: Anti-rust oil+ plastic bag+ paper box+ wooden box
2. For big ones: Anti-rust oil+ waterproof belt+ professional belt +wooden box
Application :Steel industry, oil industry, cement industry, mining & construction, papermaking machinery, rolling mill, sugar mill, vibrating screens, conveyors, air blower, transmissions, and other heavy machinery

9 mm

24 mm

7 mm

D₁

19,6 mm

D_{a max}

22 mm

d₁

14 mm

d_{a min}

11 mm

r_{a max}

0,3 mm

r_min

0,3 mm

0,015 kg

Mass

C_r

3900 N

Basic dynamic load rating, radial

C_0r

1640 N

Basic static load rating, radial

n_G

44500 1/min

Limiting speed

n_B

28500 1/min

Reference speed

C_ur

89 N

Fatigue limit load, radial

Share this product to:

Let more people see your product

How can you buy 609 Bearing on the Internet?
High quality 609 ( 0.015 kg Mass, ID: 9 mm OD: 24 mm WD: 7 mm , ABEC-5 Accuracy Class , Chrome Steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 609. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
