51412M Thrust Ball Bearing
Min. Order:
1 Piece
Payment term:
T/T, L/C
Delivery time:
15-25days
Technical Parameters:
Product Designations:
51412M
Structure:
Thrust Ball Bearing
Inside Diameter:
60 mm
Outside Diameter:
130 mm
Thickness:
51 mm
Weight:
3.30 KG
Brand:
XDB, OEM
Precision Rating:
P0,P6,P5
Bearing Material:
GCr15
Seals Type:
Open
Single direction thrust ball bearing - 51412M
Single direction or double direction thrust ball bearings. They are designed to accommodate axial loads only and must not be subjected to any radial load.
thrust ball bearings are separable, i.e. the shaft washer, housing washer(s), ball and cage assembly(s) canbe mounted separately.
Shaft washers have a ground bore to enable an interference fit. The bore of the housing washer is turned and always larger than the shaft washer bore.
single direction thrust ball bearings consist of a shaft washer, a housing washer and a ball and cage assembly. As their name implies, single direction thrust ball bearings can accommodate axial loads and locate a shaft axially, in one direction only.
| Designation ISO |
Designation GHOST |
Weight (kg) |
Dimension d×D×B |
| 51406 | 8406 | 3.94 | 30*70*28 |
| 51410M | 8410 | 1.86 | 50*110*43 |
| 53410M | 28410 | 1.92 | 50*110*45.6 |
| 51411M | 8411 | 2.62 | 55*120*48 |
| 52411M | 38411 | 4.74 | 55*120*87 |
| 51412M | 8412 | 3.30 | 60*130*51 |
| 51413M | 8413 | 4.71 | 65*140*56 |
| 51414M | 8414 | 5.10 | 70*150*60 |
| 52414M | 38414 | 9.23 | 70*150*107 |
| 51415M | 8415 | 6.62 | 75*160*65 |
| 51416M | 8416 | 8.00 | 80*170*68 |
| 51417 | 8417K | 8.55 | 85*180*72 |
| 51417M | 8417 | 8.80 | 85*180*72 |
| 53417M | 28417 | 9.09 | 85*180*77 |
| 52417M | 38417 | 16.20 | 85*180*128 |
| 51418M | 8418 | 10.10 | 90*190*77 |
| 51420 | 8420K | 13.90 | 100*210*85 |
| 51420M | 8420 | 14.00 | 100*210*85 |
| 53420+U420 | 18420K | 16.60 | 100*210*98 |
| 52420 | 38240K | 25.50 | 100*210*150 |
| 51422M | 8422 | 18.60 | 110*230*95 |
| 52422M | 38422 | 33.70 | 110*230*166 |
| 51424M | 8424 | 23.90 | 120×250×102 |
| 51426J | 8426K | 29.40 | 130*270*110 |
| 51426 | 8426 | 29.40 | 130*270*110 |
| 53426J+U426 | 18426K | 35.10 | 130*270*128 |
| 53426+U426 | 18426 | 35.30 | 130*270*128 |
| 51428 | 8428 | 31.30 | 140*280*112 |
| 52428 | 56.80 | 140×280×196 | |
| 51430 | 8430 | 39.60 | 150*300*120 |
| 51430/P5 | D8430 | 39.60 | 150*300*120 |
| 52430 | 38430 | 71.00 | 150*300*209 |
