44150/44363D Double Row Tapered Roller Bearing Size 1 1/2x3.625x2.1875 Inch

Get Latest Price

Min. Order:

1 Piece

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Mobile NO.: +86-18062246726

Technical Parameters:

Product Designations:

44150/44363D

HS Code:

8482500090

Structure:

Roller Bearing

Number of Rows:

Double

Inside Diameter:

38.1 mm

Outside Diameter:

92.075 mm

Thickness:

55.563 mm

Weight:

1.67 KG

Demensions:

38.1x92.075x55.563

Brand:

Neutral Product

Precision Rating:

Standard

Load Direction:

Radial and Thrust

Bearing Material:

Chrome Steel (Gcr15)

Cage material:

Steel

Roller Material:

Chrome Steel (Gcr15)

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Operating Temperature Range:

-40℃ to 120℃

System of Measurement:

Inch

Series:

44000

Rolling Element:

Roller

Cone Number:

44150

Cup Number:

44363D

Cone Width (B):

23.698

Cup Width (C):

39.688

Chamfer (R):

2.3

Chamfer (r):

1.5

Application:

Gearboxes, Hoisting Equipment, Rolling Mills and Machines in the Mining Industry, e.g. tunnelling machines.

44150/44363D Tapered Roller Bearing, TDO Type, Double Row, Inch Size.

Size (Inner Dia x Outer Dia x Bearing Width Across Cones): 1 1/2x3.625x2.1875 Inch (38.1x92.075x55.563 mm)

Cone Part No.: 44150

Cup Part No.: 44363D

Mini Operating Temperature:-40 °C

Max Operating Temperature:120 °C

44150/44363D Tapered Roller Bearing consists of two single inner rings (Cone) 44150 and a single piece (double) outer ring (Cup) 44363D. Besides, it is usually supplied complete with an inner-ring spacer as a pre-set assembly.

44150/44363D Tapered Roller Bearing
Type:	TDO
Series:	44000
Cone Part Number:	44150
Cup Part Number:	44363D
Bearing Weight (kg)	1.67
Main Dimensions:
	inch	mm
d-Bore:	1 1/2	38.1
D-Cup Outer Diameter:	3.625	92.075
B-Cone Width:	0.933	23.698
C-Double Cup Width:	1.5625	39.688
T-Bearing Width Across Cones	2.1875	55.563
Bearing Type:	Roller
Ring Material:	Chrome Steel
Roller Material:	Chrome Steel
Cage Material:	Stamped Steel
Precision:	Standard Precision
Load Direction:	Combined Radial and Thrust
Country of Origin:	China
HS Code:	8482500090

The configuration of the TDO provides a wide effective bearing spread, making it ideal for applications in which overturning moments are a significant load component. TDO bearings can be used in fixed positions or allowed to float in the housing bore.

Applications: gearboxes, hoisting equipment, rolling mills and machines in the mining industry, e.g. tunnelling machines.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at sales@partsservicesupply.com or contact us by Wechat or Whatsapp at +8618062246726.
