34300/34478D Double Row Tapered Roller Bearing (Size: 3x4.7812x2.0625 Inch)

Get Latest Price

Min. Order:

1 Piece

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Mobile NO.: +86-18062246726

Technical Parameters:

Product Designations:

34300/34478D

HS Code:

8482500090

Structure:

Roller Bearing

Number of Rows:

Double

Inside Diameter:

76.2 mm

Outside Diameter:

121.442 mm

Thickness:

52.388 mm

Weight:

1.98 KG

Demensions:

76.2x121.442x52.388

Brand:

Neutral Product

Precision Rating:

Standard

Load Direction:

Radial and Thrust

Bearing Material:

Chrome Steel (Gcr15)

Cage material:

Steel

Roller Material:

Chrome Steel (Gcr15)

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Operating Temperature Range:

-40℃ to 120℃

System of Measurement:

Inch

Series:

34000

Rolling Element:

Roller

Cone Number:

34300

Cup Number:

34478D

Cone Width (B):

23.012

Cup Width (C):

38.1

Chamfer (R):

Chamfer (r):

0.8

Application:

Gearboxes, Hoisting Equipment, Rolling Mills and Machines in the Mining Industry, e.g. tunnelling machines.

34300/34478D Tapered Roller Bearing, TDO Type, Double Row, Inch Size.

Size (Inner Dia x Outer Dia x Bearing Width Across Cones): 3x4.7812x2.0625 Inch (76.2x121.442x52.388 mm)

Cone Part No.: 34300

Cup Part No.: 34478D

Mini Operating Temperature:-40 °C

Max Operating Temperature:120 °C

34300/34478D Tapered Roller Bearing consists of two single inner rings (Cone) 34300 and a single piece (double) outer ring (Cup) 34478D. Besides, it is usually supplied complete with an inner-ring spacer as a pre-set assembly.

34300/34478D Tapered Roller Bearing
Type:	TDO
Series:	34000
Cone Part Number:	34300
Cup Part Number:	34478D
Bearing Weight (kg)	1.98
Main Dimensions:
	inch	mm
d-Bore:	3	76.2
D-Cup Outer Diameter:	4.7812	121.442
B-Cone Width:	0.906	23.012
C-Double Cup Width:	1.5	38.1
T-Bearing Width Across Cones	2.0625	52.388
Bearing Type:	Roller
Ring Material:	Chrome Steel
Roller Material:	Chrome Steel
Cage Material:	Stamped Steel
Precision:	Standard Precision
Load Direction:	Combined Radial and Thrust
Country of Origin:	China
HS Code:	8482500090

The configuration of the TDO provides a wide effective bearing spread, making it ideal for applications in which overturning moments are a significant load component. TDO bearings can be used in fixed positions or allowed to float in the housing bore.

Applications: gearboxes, hoisting equipment, rolling mills and machines in the mining industry, e.g. tunnelling machines.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at sales@partsservicesupply.com or contact us by Wechat or Whatsapp at +8618062246726.

Share this product to:

Let more people see your product

How can you buy 34300/34478D Double Row Tapered Roller Bearing (Size: 3x4.7812x2.0625 Inch) on the Internet?
High quality 34300/34478D ( 1.98 kg Mass, ID: 76.2 mm OD: 121.442 mm WD: 52.388 mm , 34000 Series , Double Rows , Standard Accuracy Class , Chrome Steel (Gcr15) Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 34300/34478D. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
