17098X/17245D Double Row Tapered Roller Bearing Size 0.9843x2.4409x1.5624 Inch

17098X/17245D Double Row Tapered Roller Bearing Size 0.9843x2.4409x1.5624 Inch

Min. Order:
1 Piece
Stock:
100 Piece
Port:
Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao
Payment term:
by T/T in advance
Delivery time:
2-3 days for stock, 25-30 days for bulk production
Skype online
QQ online
Mobile NO.: +86-18062246726
Technical Parameters:
Product Designations:
17098X/17245D
HS Code:
8482500090
Structure:
Roller Bearing
Number of Rows:
Double
Inside Diameter:
25.001 mm
Outside Diameter:
61.999 mm
Thickness:
39.685 mm
Weight:
0.6 KG
Demensions:
25.001x61.999x39.685
Brand:
Neutral Product
Precision Rating:
Standard
Load Direction:
Radial and Thrust
Bearing Material:
Chrome Steel (Gcr15)
Cage material:
Steel
Roller Material:
Chrome Steel (Gcr15)
Transport Package:
Standard Export Package
Shipping Ways:
by Sea or Air
Country of Origin:
China
Operating Temperature Range:
-40℃ to 120℃
System of Measurement:
Inch
Series:
17000
Rolling Element:
Roller
Cone Number:
17098X
Cup Number:
17245D
Cone Width (B):
16.566
Cup Width (C):
36.259
Chamfer (R):
1.5
Chamfer (r):
0.8
Application:
Gearboxes, Hoisting Equipment, Rolling Mills and Machines in the Mining Industry, e.g. tunnelling machines.
17098X/17245D Double Row Tapered Roller Bearing Size 0.9843x2.4409x1.5624 Inch

17098X/17245D Tapered Roller Bearing, TDO Type, Double Row, Inch Size.

Size (Inner Dia x Outer Dia x Bearing Width Across Cones): 0.9843x2.4409x1.5624 Inch (25.001x61.999x39.685 mm)

Cone Part No.: 17098X

Cup Part No.: 17245D

Mini Operating Temperature:-40 °C

Max Operating Temperature:120 °C

17098X/17245D Tapered Roller Bearing consists of two single inner rings (Cone) 17098X and a single piece (double) outer ring (Cup) 17245D. Besides, it is usually supplied complete with an inner-ring spacer as a pre-set assembly.

17098X/17245D Tapered Roller Bearing

Type:

TDO

Series:

17000

Cone Part Number:

17098X

Cup Part Number:

17245D

Bearing Weight (kg)

0.6

Main Dimensions:



inch

mm

d-Bore:

0.9843

25.001

D-Cup Outer Diameter:

2.4409

61.999

B-Cone Width:

0.6522

16.566

C-Double Cup Width:

1.4275

36.259

T-Bearing Width Across Cones

1.5624

39.685

Bearing Type:

Roller

Ring Material:

Chrome Steel

Roller Material:

Chrome Steel

Cage Material:

Stamped Steel

Precision:

Standard Precision

Load Direction:

Combined Radial and Thrust

Country of Origin:

China

HS Code:

8482500090

The configuration of the TDO provides a wide effective bearing spread, making it ideal for applications in which overturning moments are a significant load component. TDO bearings can be used in fixed positions or allowed to float in the housing bore.

Applications: gearboxes, hoisting equipment, rolling mills and machines in the mining industry, e.g. tunnelling machines.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at sales@partsservicesupply.com or contact us by Wechat or Whatsapp at +8618062246726.


Share this product to:     Let more people see your product
How can you buy 17098X/17245D Double Row Tapered Roller Bearing Size 0.9843x2.4409x1.5624 Inch on the Internet?
High quality 17098X/17245D ( 0.6 kg Mass, ID: 25.001 mm OD: 61.999 mm WD: 39.685 mm , 17000 Series , Double Rows , Standard Accuracy Class , Chrome Steel (Gcr15) Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 17098X/17245D. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
